Unique Shaped Blade avoids Chipping

The blade is the most critical part of the product. MCC blade is manufactured of special alloy steel with unique heat treatment in providing you with the best performance and longer lifespan than others. This improved unique blade was designed to avoid the damage especially when the long piece of rebar is cut. The long stick rebar tends to tilt or be away from the bottom of cutting hollow slot where the leverage is maximum and occasionally cause the blade damages. MCC's new blade is designed for rebar to be on the bottom position while being guided by the blades.

Five enclosed holes for attaching to board

The four enclosed holes on the flame and one hole on the foot pedal are designed to be attached to a board or floor when you need more stability in operation. Many similar products have round arch shape not enclosed holes like our previous model CB-16 which might be out of the secure position on the board during operation. The enclosed holes ensure that the cutter is always in a secure fashion.

Improved Frame Base for more stability

MCC re-designed the frame outline and interior in constructing a well-balanced, compact, and light weight feature.

Strengthened Bending Mechanism

Frankly, the previous model CB-16 has weak point. When the #5(5/8) Grade 60 is bent, the excessive force occurs on the roller and the roller pin. After numerous job site operations, the grease in the roller dries up. It causes tougher conditions to the roller pin and unfortunately, the roller pin occasionally will pop out due to the lack of lubricant between the roller and the pin. SCB-16 has reinforced pin-attaching system to minimize this damage for the toughest conditions.

Cam Mechanism for improved leverage

The leverage was improved by 30% less effort when the #5 Grade 60 is cut by the cam mechanism. This allows us to obtain the most leverage at the maximum cutting point. This product provides the highest productivity.

Specifications:

Model No.: SCB-16
Cutting Capacity: up to 5/8", #5 Grade 60 (420 Mpa)
Bending Capacity: up to 5/8", #5 Grade 60 (420 Mpa)
Bending Degree Capability: 0 to 180 degree
Bending Diameter: 2 1/2"
Net Weight: 38 lbs
Shipping Weight: 41 lbs
Overall Dimension: 8"(H) - 6"(W) - 50"(L)
Packaging: Cardboard carton
Replacement Blade No.: SCBE-16
Replacement Blade Components: #3, #4, #28
