Abaco Machines Dehydrator - Stainless Steel

The Abaco Dehydrator is a dehydration system for the fast collection and trapping of the abrasive mud produced by machining and finishing marble, granite, and other stone. The Dehydrator is an economical, one step method in separating sludges and slurries from water. It is constructed of stainless steel and consists of four basic components: electric pump, mud holding tank, clean water tray, and filter bags. The Abaco Dehydrator has no moving parts and requires minimal maintenance.

Features:

Abaco Dehydrator (Sludge Filter) is a dehydrator system for the fast collection and trapping of the abrasive mud produced by machining and finishing marble, granite, and other stones.
Abaco Dehydrator (Sludge Filter) is an economical one step method in separating and dewatering sludge and slurries.
Dehydrator is constructed of Stainless Steel and consists of four basic components: pump, mud holding tank, filter bags and filtered water pan.
Abaco Dehydrator (Sludge Filter) has no moving parts and requires minimal maintenance.

Included with the Dehydrator:

4 - Plastic Curtains
2 - Stainless Steel Curtain Rods
1 - 5m Industrial Water Hose
3 - Industrial Hose Clamps
20 - Polypropylene bags
1 - Pit Cleaning Tool/Air Stick
1 - Solid Rubber Drain Plug

Specifications:

Deminsions: 2270x2220x600
Weight: 280
Power: 240V/50Hz
Weekly Output Capacity (dry mud): 622L
Mud Holding Tank Capacity: 550L
Sump Pump: 6E-CIA-SFS 189 or equivalent
Float Switch: Piggy Back Mechanical Float Switch
Bag Dimension: 350x1200 (Diameter x Length)
Construction Material: Stainless Steel
Flange for Bag: 350 Aluminum
Fasteners: Stainless Steel
Valves: 50mm BSP Brass Nickel Plated
