Mikasa Plate Compactor Reversible Diesel 525kg MVH-508DSZN FT28DSZN-UNIT

Mikasa Plate Comp Rev Diesel 525kg MVH-508DSZN FT28DSZN-UNIT

Mikasa reversible plate compactor Model MVH508DSZN, ideal for high production and efficient compaction of sand, gravel and cohesive soils in trenches and large construction projects. Powered by Hatz, 14.1Hp diesel engine. (Weight 567 Kg)

Mikasa Reversible Plate Compactors are ideal for the efficient compaction of sand, gravel and cohesive soils in trenches and large construction projects. They offer high compaction capacity, superior travel speeds and feature fully hydraulic direction control for easy direction change. They are ideally suited for civil construction works, drainage contractors and the rental industry.

Specifications:

• Operating Weight Without Extension Plates: 525kg
• Plate Size (W X L) Without Extension Plates: 650 x 900mm
• Operating Weight With Extension Plates: 567Kg
• Plate Size (W X L) With Extension Plates: 800 x 900mm
• Centrifugal Force (Max): 65kN
• Vibration Frequency: 4,150VPM
• Max Travel Speed: 29m/min
• Max Gradeability: 35%
• Max Compacted Area: 1392m/h
• Engine Make: Hatz
• Engine Model: 1D81S
• Max Rated Power: 14.1hp
• Fuel Type: Disel
