Mikasa Compactors Reversible Diesel Plate MVH-158DY FT272784-UNIT

Mikasa Compactors Reversible Diesel Plate MVH-158DY FT272784-UNIT

Mikasa Reversible Plate Compactors set the standard for efficient compaction of sand, gravel and cohesive soils in trenches and large construction projects. They offer high compaction capacity, superior travel speeds and feature fully hydraulic direction control for easy direction change. They are ideally suited for civil construction works, drainage contractors and the rental industry.

Features

Forward/reverse control lever

• Built-in actuator.
• Seamless and smooth transition between both forward and reverse motions.

Cyclonic air filtration system

Anti-vibration & adjustable handle

• Reduced operator fatigue.
• Height adjustable handle for improved operator comfort.

Lifting hook

Full engine protection frame

• Robust frame provides superior protection against engine damage.
• Hinge design for easy engine access maintenance and servicing.

Yanmar diesel engine

Sealed clutch and belt guard

Specification

• Operating Weight
• Without extension plates(kg): 164
• With extension plates(kg): N/A
• Plate Size (WxL)
• Without extension plates(mm): 430 x 700
• With extension plates(mm): N/A
• Centrifugal Force(Max) (kN): 25
• Vibration Frequency(VPM): 5,400
• Max Travel Speed(m/min): 26
• Max Gradeability(%)
• Max Compacted Area(m/h): 670
• Engine Make/Model: YanmarL48N
• Max Rated Power(Hp): 4.7
• Average HAV(m/s2): N/A
• Fuel Type: Diesel
• Product Code: FT272784-UNIT
